H Beam

new substitute material that the National Development and Reform Commission and other relevant departments vigorously promote and use, and is the main material of steel structure engineering in many countries. Such as: nuclear industry, shipbuilding industry

Keyword:

H Beam

Category:

H Beam

tel

Hotline:

+86-15030559799

Contacts
Consulting

Product Details

H-beam steel is an economical and efficient section profile material featuring more optimal cross section area distribution and more reasonable specific strength. It is similar to the letter “H” as its name indicates. It is characterized by strong bending resistance, simple construction, cost saving and light weight.



H-beam steel is an emerging alternative material extremely promoted by the National Development and Reform Commission and other relevant authorities as well as a major material in steel structure engineering of many countries, such as nuclear industry, shipbuilding, aerospace, petrochemical industry, metallurgy, electric power, coal, machinery, railway, bridges, municipal construction, expressway, the mid and high-rise building, civil house, light steel villa, hospital steel structure, etc.



22    33    ee



Dimension and theoretical weight of H-shaped steel(GB/T11263-1998)
   Model
(h * w)		 Section size
mm		 Cross-sectional area
cm²		 Theoretical weight
kg/m
H×B T1 T2 R
HW wide flange 100×100 100×100 6 8 10 21.9 17.2
125×125 125×125 6.5 9 10 30.31 23.8
150×150 150×150 7 10 13 40.55 31.9
175×175 175×175 7.5 11 13 51.43 40.4
200×200 200×200 8 12 16 64.28 50.5
200×204 12 12 16 72.28 56.7
250*250 250×250 9 14 16 92.18 72.4
#250×255 14 14 16 104.7 82.2
300*300 #294*302 12 12 20 108.3 85
300*300 10 15 20 120.4 94.5
300*305 15 15 20 135.4 106
350*350 344*348 10 16 20 146 115
350*350 12 19 20 173.9 137
400*400 388*402 15 15 24 179.2 141
394*398 11 18 24 187.6 147
394*405 18 18 24 215.5 169
400*400 13 21 24 219.5 172
400*408 21 21 24 251.5 197
414*405 18 28 24 296.5 233
428*407 20 35 24 361.4 284
458*417 30 50 24 529.3 415
498*432 45 70 24 770.8 605
HM middle flange 150*100 148*100 6 9 13 27.25 21.4
200*150 194*150 6 9 16 39.76 31.2
250*175 244*175 7 11 16 56.24 44.1
300*200 294*200 8 12 20 73.03 57.3
350*250 340*250 9 14 20 101.5 79.7
400*300 390*300 10 16 24 136.7 107
450*300 440*300 11 18 24 157.4 124
500*300 482*300 11 15 28 146.4 115
488*300 11 18 28 164.4 129
600*300 582*300 12 17 28 174.5 137
588*300 12 20 28 192.5 151
594*302 14 23 28 222.4 175
HN narrow flange
100*50 100*50 5 7 10 12.16 9.54
125*60 125*60 6 8 10 17.01 13.3
150*75 150*75 5 7 10 18.16 14.3
175*90 175*90 5 8 10 23.21 18.2
200*100 198*99 4.5 7 13 23.59 18.5
200*100 5.5 8 13 27.57 21.7
250*125 248*124 5 8 13 32.89 25.8
250*125 6 9 13 37.87 29.7
300*150 298*149 5.5 8 16 41.55 32.6
300*150 6.5 9 16 47.53 37.3
350*175 346*174 6 9 16 53.19 41.8
350*175 7 11 16 63.66 50
400*150 400*150 8 13 16 71.12 55.8
400*200 396*199 7 11 16 72.16 56.7
400*200 8 13 16 84.12 66
450*150 450*150 9 14 20 83.41 65.5
450*200 446*199 8 12 20 84.95 66.7
450*200 9 14 20 97.41 76.5
500*150 500*150 10 16 20 98.23 77.1
500*200 496*199 9 14 20 101.3 79.5
500*200 10 16 20 114.2 89.6
506*201 11 19 20 131.3 103
600*200 596*199 10 15 24 121.2 95.1
600*200 11 17 24 135.2 106
606*201 12 20 24 153.3 120
700*300 692*300 13 20 28 211.5 166
700*300 13 24 28 235.5 185
800*300 792*300 14 22 28 243.4 191
800*300 14 26 28 267.4 210
900*300 890*299 15 23 28 270.9 213
900*300 16 28 28 309.8 243
912*302 18 34 28 364 286
1000*300 970*297 16 21 28 279.96 219.8
980*298 17 26 28 319.46 250.8
990*298 17 31 28 349.26 274.2
1000*300 19 36 28 399.1 313.3
1008*302 21 40 28 443.22 347.9
Dimension and theoretical weight of H-shaped steel(GB/T11263-2017)
  Model
(h * w)		 Section size
mm		 Cross-sectional area
cm²		 Theoretical weight
kg/m
H×B T1 T2 R
HW wide flange 100×100 100×100 6 8 8 21.58 16.9
125×125 125×125 6.5 9 8 30 23.6
150×150 150×150 7 10 8 39.64 31.1
175×175 175×175 7.5 11 13 51.42 40.4
200×200 200×200 8 12 13 63.53 49.9
200×204 12 12 13 71.53 56.2
250*250 244*252 11 11 13 81.31 63.8
250×250 9 14 13 91.43 71.8
#250×255 14 14 13 103.9 81.6
300*300 #294*302 12 12 13 106.3 83.5
300*300 10 15 13 118.5 93
300*305 15 15 13 133.5 105
350*350 338*351 13 13 13 133.3 105
344*348 10 16 13 144 113
344*354 16 16 13 164.7 129
350*350 12 19 13 171.9 135
350*357 19 19 13 196.4 154
400*400 388*402 15 15 22 178.5 140
394*398 11 18 22 186.8 147
394*405 18 18 22 214.4 168
400*400 13 21 22 218.7 172
400*408 21 21 22 250.7 197
414*405 18 28 22 295.4 232
428*407 20 35 22 360.7 283
458*417 30 50 22 528.6 415
498*432 45 70 22 770.1 604
500*500 492*465 15 20 22 258 202
502*465 15 25 22 304.5 239
502*470 20 25 22 329.6 259
HM middle flange 150*100 148*100 6 9 8 26.34 20.7
200*150 194*150 6 9 8 38.1 29.9
250*175 244*175 7 11 13 55.49 43.6
300*200 294*200 8 12 13 71.05 55.8
298*201 9 14 13 82.03 64.4
350*250 340*250 9 14 13 99.53 78.1
400*300 390*300 10 16 13 133.3 105
450*300 440*300 11 18 13 153.9 121
500*300 482*300 11 15 13 141.2 111
488*300 11 18 13 159.2 125
550*300 544*300 11 15 13 148 116
550*300 11 18 13 166 130
600*300 582*300 12 17 13 169.2 133
588*300 12 20 13 187.2 147
594*302 14 23 13 217.1 170
HN narrow flange 100*50 100*50 5 7 8 11.84 9.3
125*60 125*60 6 8 8 16.68 13.1
150*75 150*75 5 7 8 17.84 14
175*90 175*90 5 8 8 22.89 18
200*100 198*99 4.5 7 8 22.69 17.8
200*100 5.5 8 8 26.66 20.9
250*125 248*124 5 8 8 31.98 25.1
250*125 6 9 8 36.97 29
300*150 298*149 5.5 8 13 40.8 32
  300*150 6.5 9 13 46.78 36.7
350*175 346*174 6 9 13 52.45 41.2
350*175 7 11 13 62.91 49.4
400*150 400*150 8 13 13 70.37 55.2
400*200 396*199 7 11 13 71.41 56.1
400*200 8 13 13 83.37 65.4
450*150 446*150 7 12 13 66.99 52.6
450*151 8 14 13 77.49 60.8
450*200 446*199 8 12 13 82.97 65.1
450*200 9 14 13 95.43 74.9
475*150 470*150 7 13 13 71.53 56.2
475*151.5 8.5 15.5 13 86.15 67.6
482*153.5 10.5 19 13 106.4 83.5
500*150 492*150 7 12 13 70.21 55.1
500*152 9 16 13 92.21 72.4
504*153 10 18 13 103.3 81.1
500*200 496*199 9 14 13 99.29 77.9
500*200 10 16 13 112.3 88.1
506*201 11 19 13 129.3 102
550*200 546*199 9 14 13 103.8 81.5
550*200 10 16 13 117.3 92
600*200 596*199 10 15 13 117.8 92.4
600*200 11 17 13 131.7 103
606*201 12 20 13 149.8 118
625*200 625*198.5 13.5 17.5 13 150.6 118
630*200 15 20 13 170 133
638*202 17 24 13 198.7 156
650*300 646*299 12 18 18 183.6 144
650*300 13 20 18 202.1 159
656*301 14 22 18 220.6 173
700*300 692*300 13 20 18 207.5 163
700*300 13 24 18 231.5 182
750*300 734*299 12 16 18 182.7 143
742*300 13 20 18 214 168
750*300 13 24 18 238 187
758*303 16 28 18 284.8 224
800*300 792*300 14 22 18 239.5 188
800*300 14 26 18 263.5 207
850*300 834*298 14 19 18 227.5 179
842*299 15 23 18 259.7 204
850*300 16 27 18 292.1 229
858*301 17 31 18 324.7 255
900*300 890*299 15 23 18 266.9 210
900*300 16 28 18 305.8 240
912*302 18 34 18 360.1 283
H1000*300 970*297 16 21 18 276 217
980*298 17 26 18 315.5 248
990*298 17 31 18 345.3 271
1000*300 19 36 18 395.1 310
1008*302 21 40 18 439.3 345



The company is the first level agent of Jinxi, Antai, Baotou Steel and Wanteng H-shaped steel, distributing H-shaped steel of various specifications. At the same time, it is also the distributor of steel sheet piles in Jinxi, which can provide various specifications of hot-rolled steel sheet piles, Z-shaped steel sheet piles, Larsen steel sheet piles, No. 3 and No. 4 steel sheet piles and other series of products. Our company, as one of the largest suppliers of section steel in China, has excellent quality and low price, and a complete range of products, which can meet the various construction requirements of customers. To provide customers in Northwest China with high quality and low price products and warm and thoughtful services, making full preparations for the establishment of the branch company in the later period.
